  HP 4145A and 4145B Repair and Software


Agilent, Keysight HP 4145A Semiconductor Parameter Analyzer

S.I. repairs the venerable Hewlett Packard (now Agilent, Keysight) 4145A and 4145B semiconductor parameter analyzers.  We also have the boot software available.  The 4145B units could copy their own boot 3.5" floppies, but the 4145A uses a 5.25" floppy disk that had to be factory copied.  We can supply both 3.5" and 5.25" diskettes for people who have lost/damaged the originals or who bought a used machine without the boot disk.  We have several different versions available for the 4145B.  The HP part number for the 5.25" boot disk is 04145-85100 (Rev. A5). Hewlett Packard P/N 16261.

We also repair these units.  They were notorious for having display problems and failed floppy drives.  We stock refurbished display modules and floppy drives (they are proprietary Hewlett packard, so you can't just drop in a PC floppy).

We also occasionally have complete refurbished units available for sale.  They are a great value for their capabilities.  The 4145A versions we sell for approximately $1500 and the 4145B versions sell for approximately $5500 (depending on options and cosmetic condition) with warranty.  Please email us for availability.

Please contact us if you need the software to run these venerable machines.  They will not work without a boot floppy.  If you are getting the error M02 (M_02) on the screen, the software is missing/damaged (or the drive has a fault) and that is as far as you will go without it.  There is no provision to boot these machines from the GPIB (HPIB) port.
HP Agilent, Keysight 4145B Semiconductor Parameter Analyzer

For users who need the additional functionality of the more advanced Agilent, Keysight 4155A/B and 4156A/B/C, we can supply these machines, but they are much more expensive (approximately $17,000.00, depending on exact model and options).  Most users, however, will find the original 4145 series adequate.


Reference information for the (Agilent, Keysight) 4145A/B and test fixture 16058A:
HP 4145A Operation/Service Manual
HP 4145A Operation/Service Manual (higher resolution scan)
HP 4145B Operation Manual
HP 4145B Operation/Service manual (higher resolution scan)
HP 16058A Test Fixture Operation Manual


Reference information for the HP (Agilent, Keysight) 4085A Switching Matrix ans 4084A/B Switch Matrix Controller:
HP 4085A Switch Matrix User Manual
HP 4062A (HP 4084A & 4085A) Parameter Test System Manual
IC-CAP (Agilent, Keysight 85190A) HP 4084/4085 Control Software Reference


HP Application Notes:
DC Parametric Analysis of Semiconductor Devices
Parametric Analysis for Electronic Components


Please see our shipping information page for packing and shipping of your valuable instrument: Shipping Cautions


Please call us at 920-955-3693 or email sales@siliconinvestigations.com



Last Modified May 2, 2017
